Masport Riverstone Wood Fire
Masport Riverstone Wood Fire
The Riverstone wood fire is the perfect heating solution for small and medium rooms. Its large 8mm radiant top plate can be used for cooking, and its built-in ashpan ensures that disposal of ash is as easy and convenient as possible.
Features:
- Designed to heat small to medium sized areas - up to 190m2
- Large 8mm radiant cook top
- 6mm, durable steel firebox
- Lined with masonry fire bricks and a steel baffle for efficient burning
- Built-in ashpan for easier ash disposal
- Optional 2-speed fan for convection heating
- 10-year extensive firebox warranty under normal use and service
- 1-year warranty on all internal fire parts
- Made and designed in New Zealand
Specifications
Specifications:
| Finish | VHT Black |
| Firebox Material | Steel |
| Est. Peak Output | 19kW |
| Approx. Heat Area | 190 sq. metres |
| Emissions | 1.3g/kg |
| Efficiency | 60% |
| Circulation | Optional 2-speed convection fan |
| Log Size | 400mm |
Dimensions:
700mm (W) x 576mm (D) x 720mm (H)
Firebox Dimensions: 450mm (W) x 389mm (D) x 323mm (H)
Manuals
Masport Riverstone Wood Fire Installation Specifications
Masport Riverstone Wood Fire Spec Sheet
Masport Wood Fire Installation Manual
Masport Wood Fire Owners Manual
Flue Options
To complete any wood heater installation a flue kit and flashing will be required. These are available for purchase as standard kits online which will suit straightforward, vertical, single-storey applications. Depending on your site specifics you may also need a hearth, or other components that aren’t available on our website.
We have heater experts available in store to give advice for wood heater installations, so if you have any questions call 1300 300 227 or drop into your local outlet.
|
Standard Flue Kit |
Includes |
|
SWH-6101 |
· Anti-down draught hat SS · 2 x 10” galvanised flue lengths · 2 x 8” galvanised flue lengths · 2 x 6” SS flue lengths · 10” ceiling ring galvanised · 2 x 6” black painted SS flue lengths · SS half shield |
|
SWH-6136 |
· Anti-down draught hat SS · 2 x 10” galvanised flue lengths · 2 x 8” galvanised flue lengths · 4 x 6” SS flue lengths · 10” ceiling ring galvanised · 2 x 8” black painted SS mesh flue length |
|
Standard Flashing |
Suits |
|
DFE108B |
Metal roof, 170-355mm external flue |
|
DNL108B |
Tile roof, 175-300mm external flue |
|
Standard Flashing |
Suits |
|
DFE108B |
Metal roof, 170-355mm external flue |
|
DNL108B |
Tile roof, 175-300mm external flue |
